A Guide to The Mack Truck Fault Codes List – Everything You Need To Know

A Guide to The Mack Truck Fault Codes List – Everything You Need To Know

Founded in 1900 as the Mack Brothers Company, Mack Trucks, Inc. is an American truck manufacturing company and a former manufacturer of buses and trolley buses. Started in Brooklyn, the company moved its headquarters to Allentown, Pennsylvania, five years later in 1905. It remained there for over a century till in 2009, the company relocated its headquarters to Greensboro, North Carolina.

The Mack Brothers Company manufactured its first truck in 1905 and adopted its present name Mack Trucks in 1922. Since 2000, Mack Trucks has been a subsidiary of Volvo, which purchased Mack and its former parent company Renault.

Jaltest CV Commercial Vehicles Diagnostic Kit

Mack Trucks has truck and component and system manufacturing facilities spread throughout the world. Its products are made in Lower Macungie, Pennsylvania, and Salem, Virginia. It also has assembly lines in Pennsylvania, Australia, and Venezuela.

Mack Trucks has made a name in the vocational and on-road vehicle market and is among the top producers in this niche. Its products include Class 8 through to Class 13 trucks and are sold in more than 45 countries worldwide.

Now that we have a fair understanding of Mack Trucks, let us dive into the Mack truck fault codes list in this post and learn how to keep your fleet of these trucks on the road without downtime.

Need help with your Mack Truck Models?

Click Here

What Are Mack Fault Codes

Every modern vehicle, even construction and material handling equipment, has onboard computers. It is mandatory by law and helps to keep a tab on the health of the vehicle. Any malfunction is reflected on the display screen of the onboard computer in the form of fault codes in alpha-numeric format.

If you go through the Mack fault codes list you will see that fault codes are specific to different models of the trucks even though the type of malfunction might be the same. Hence, Mack Trident fault codes will not match that of other models.

Fault codes, often called Diagnostic Trouble Codes (DTCs), are used to are used to identify and diagnose malfunctions in a vehicle's on-board diagnostics (OBD) system. The codes pop up on the display panel of the OBD, generally tucked away below the dashboard on the driver’s side. At this juncture, connect our Jaltest Mack truck diagnostic software to the OBD and get a clear interpretation of what the code from the Mack truck fault codes list indicates.

The software will tell you what the fault is and how to rectify and clear the fault code. The functioning of this maintenance tool is backed by live information and technical data in real-time to accurately pinpoint the fault and rectify it.

Additionally, you are provided with detailed wiring diagrams so that you know exactly the location of the fault. Hence, any minor malfunction is traced from the Mack truck fault codes list and rectified before it becomes a major issue.

How To Read Mack Fault Codes

Here are the components that make up the codes in the Mack fault codes list.

  • SA (Source Address): Indicates the source of the fault code, for example, "16" for the engine ECU.
  • DTC (Diagnostic Trouble Code): A code that identifies the specific problem.
  • P (Powertrain): Indicates that the fault code is related to the powertrain.
  • SPN (Suspected Parameter Number): Tells you the circuit where the fault occurred.
  • FMI (Failure Mode Indicator): Explains the reason the fault code was set.

For example, let us take SA 16 DTC P113000 from the Mack engine fault codes.  The breakup will be as follows:

  • SA 16: Engine ECU
  • DTC P1130: After-treatment Hydrocarbon Air Purge Valve
  • 00: (stuck closed) - failure mode

Given below are some other common Mack fault codes and their interpretations.

  • SA 16 DTC P20EE00: NOx Catalyst - Conversion Efficiency Low.
  • 6-2 Date Line Input (Proprietary) no signal: Indicates a problem with the proprietary data line.
  • 6-3 SAE/ATA J1708 Serial Line No Signal: Indicates a problem with the SAE/ATA J1708 serial line.
  • 8-5: Fault with the #5 EUP (Engine Unit Parameter), the actual problem depends on the fault FMI.
  • 3-5: Fault with engine brake output #1 - the front head engine brake solenoid.
  • 4-5: Wastegate fault code.
  • 1-4: Ambient Air Temperature (AAT) Sensor fault.
  • 3-1: Engine running at greater than 30% load for at least 60 seconds and the exhaust temperature is less than 100°F (82°C) for 2 seconds.
  • 5079-05 m128 and 5080-05 m128: These codes are related to the TCM (Transmission Control Module).
  • SA 16 DTC P113000: After-treatment Hydrocarbon Air Purge Valve stuck closed.

When you connect the Jaltest Mack trucks diagnostic software to the OBD, and if one of the hundreds of codes from the Mack fault codes list shows up, you will be guided on how to resolve the issue on your premises. You do not have to fall back on bulky manuals or wait for certified engineers to show up to get your Mack truck back on the road without downtime.

Getting The Most From Jaltest Mack Truck Diagnostic Software

When you use the Jaltest Mack truck diagnostic software, you are getting service help from one of the leaders in this niche. Our user-friendly tool not only helps in the diagnosis of Mack fault codes that are of a temporary nature but also ones that are permanent and require complex resolutions. So, how do you get the most out of the Jaltest Mack truck maintenance tool?

There are two ways to do it and, in both instances, you will be guided closely by the software while going through the procedure.

In the first instance, connect the tool to the OBD and choose the option “full system scan” in the diagnostic menu. The software will scan all systems and components to identify any fault codes present in your Mack truck or whether all systems are functioning as they should and none have gone to the fault code stage. Any minor issue is identified and rectified before it becomes a major one.

This process is typically deemed to be preventive maintenance and must be carried out periodically to confirm the good health of Mack trucks. Generally, any minor fault codes detected in this process are minor and go away within a few driving cycles without the need for any major rectification activity.

The second process of clearing the Mack truck fault codes list is through the “scan by symptom” mode. This is a straightforward process as you are aware of the fault code and can implement precise solutions. You need to check the fault code through our software, identify the fault and then follow the directions of the software to clear it. You will be helped by technical data in real-time while you carry out the solution.

The benefit of using the Jaltest software is that apart from resolving issues that arise with Mack trucks, you can also pre-empt any malfunction through periodical full system scans. Combined, you are assured that your fleet will face minimum downtime and will be on the roads without a break.

Read more about Mack trucks fault codes clearance.

Clearing Mack ABS Fault Codes

The ABS light on Mack trucks comes on when there is a fault with the ABS system. It might be due to several factors, usually a faulty sensor, wiring, or issues with the Actuation Systems. You must press the ABS diagnostic button, hold it for three seconds, and get one of the following Mack fault codes.

  • ABS Code 36: Indicates a problem with the ABS modulator valve, possibly a faulty sensor or wiring.
  • ABS Code 97: Signifies a problem with the ABS system's power supply, potentially a faulty relay, wiring, or control module.
  • ABS Code 107: Points to a wheel speed sensor fault, suggesting an issue with the sensor or its wiring.
  • ABS Code 12: Indicates that the system is working correctly and serves as an initial indication that the diagnostic process has started.

At this point, connect the Jaltest Mack diagnostic tool to the OBD and follow the instructions to clear the specific fault code. Since Mack is now a subsidiary of Volvo, you can choose from Volvo Mack fault codes to implement cutting-edge solutions through our maintenance tool.

Mack Truck Engine Fault Codes and Forced Regens

A Diesel Particulate Filter (DPF) is present in all diesel-powered engines. Its role is to trap soot and particulate matter in it while letting out the emissions. Hence, it makes for a cleaner environment and its presence in diesel engines is now mandated by law.

When soot accumulates in the DPF, the performance of the engine is affected and in extreme cases, the engine might seize up and the vehicle might go into limp mode. This happens when passive regens cannot clear the filter of particulate matter.

When a code corresponding to soot buildup shows up on the Mack truck engine fault codes list our software will guide you on clearing the fault. It entails running the truck at 70km/h for 10 minutes or if the truck is stationary, run the engine at high rev for about 40 minutes. The rise in temperature of the emission gasses in both instances burns away the soot buildup and clears the DPF.

For cases where the clogging of the DPF is more than 75%, it is advisable to undertake manual cleaning and not through our Jaltest software

Summing Up

The Jaltest Mack truck fault codes list software is an optimized tool that ensures that your fleet is always in high-performance mode. Simply enter the model of your truck, the fault code that shows on the OBD, and be guided on action to be taken to get dealer-level servicing.

Our software is very user-friendly and easy to navigate. Downloading it on your diagnostic laptop does not require any elaborate configuration or setup process. Connect it to the OBD and you are ready to start fault code diagnosis and rectification.

Finally, we provide three updates to the software every year. New technologies are being implemented in Mack trucks continually, and through regular updates, we ensure that our maintenance tool never becomes obsolete.
